Car Painting Infrared Curing Light Short Wave Infrared Heat Lamp
6*1000W
Roll these lamps to your work surface and position the head
anywhere along the stand, 18”-30” from what you want to heat. Use
for spot-drying paint, adhesive, and other surface coatings and
fillers. They’re also known as infrared and radiant heaters.
Adjustable-temperature lamp lets you regulate heat using three
switch controls and up to seven bulbs (not included). Lamp is not
for use with water-based primers and paint.
Fixed-temperature lamps have a head that rotates for horizontal or
vertical positioning.
Note: Do not use in hazardous locations, such as enclosed areas
exposed to fumes.
H-shaped industrial safety design base
Make the operation of tire position more convenient
Infrared lamps are electrical devices which emit infrared
radiation. Infrared lamps are commonly used in radiant heating for
industrial processes and building heating. Infrared LEDs are used
for communication over optical fibers and in remote control
devices. Infrared lamps are also used for some night vision devices
where visible light would be objectionable. Infrared lamp sources
are used in certain scientific and industrial instrument for
chemical analysis of liquids and gases; for example, the pollutant
sulfur dioxide in air can be measured using its infrared absorption
characteristics.
Double light disc structure. Aluminum alloy can reduce load,
prevent corrosion and dissipate heat quickly
Each tube has a CE mark
Reliable quality and long life
Applicable power supply voltage: 220V-240V
50/60HZ
Boot power: 6 x 1100W
Temperature: 40 ℃ -100 ℃
Baking area: 2000 × 1200mm
Products Specifications :
- Short wave infrared paint dryer
- CE Registered
- Digital Display to show remaining cure time Flash and Bake cycles
- Ideal for waterbased and solvent paints
- Convenient height adjustment
- Coverage Area 1.2m x 0.9m
- 6*1000 watt bulbs
Products Advantage :
1.The Lamshade is made of high purity aluminum alloy which is good
for heat dissipation, imported 304 stanless steel mirror reflector.
Aluminum alloy injection molding lamp, anti high temperature, anti
deformation, heigh-grade and utillty.
2.Shortwave Infrared Baking Light heats objects directly which
reducing energy costs up to 75%.
3.The shortwave infrared light through the paint film and penetrate
into the depth of the molecular structure.
Products Parameter :
| Power of Light | 6*1000W |
| Curing area | 1200×2000mm |
| Temperature | 40°C-100°C |
| Set Time | 0min-99mins adjustable |
| Power Supply | 220v,50Hz |
